Equipped with high-sensitivity touch interaction technology, it features high touch accuracy. For instance, the touch accuracy of some products can reach ±2mm, with a touch height of 3.0mm, and it supports 20-point touch.
Product Features
High-precision touch control
Equipped with high-sensitivity touch interaction technology, it features high touch accuracy. For instance, the touch accuracy of some products can reach ±2mm, with a touch height of 3.0mm, and it supports 20-point touch. It can perform touch control, whiteboard writing, text editing and other operations with fingers, styluses, etc. It has a sensitive response, smooth writing, supports gesture operation, and is convenient for zooming in and moving the picture.
Product parameters
Screen Size | 110-inch | |||||
Dot Pitch(mm) | 0.78 | 0.93 | 1.25 | 1.56 | 1.87 | 2.5 |
Pixel | Real Pixel | combination of real and imaginary | ||||
Lamp Panel Size(mm) | 150*168.75 | 300*168.75 | ||||
Resolution | 192*216 | 320*180 | 240*135 | 192*108 | 160*90 | 120*68 |
Scanning Method | 1/54 | 1/54 | 1/60 | 1/271/54 | 1/45 | 1/40 |
Surface Hardness | 4H | |||||
Surface Process | Matte finish | |||||
Display unit size(mm) | 600*337.5*35.5 | |||||
Screen size(mm) | 2400*1350 | |||||
Display Unit Weight | ~4kg | |||||
Unit Resolution | 768*432 | 640*360 | 480*270 | 384*216 | 320*180 | 240*136 |
Pixel density/m | 1638400 | 1137777 | 640000 | 409600 | 284444 | 161186 |
Screen Resolution | 4608*2592 | 3840*2160 | 2880*1620 | 2304*1296 | 1920*1080 | 1440*816 |
Circuit Scheme | Common | Common anode circuit | Common | |||
cathode | cathode | |||||
circuit | circuit | |||||
Flash calibration memory | Support | |||||
Control System | Nova | |||||
White Balance Brightness | Standard 600nits | 1200nits | Standard 600nits | |||
Refresh Rate | 3840Hz | |||||
Contrast Ratio | 10000:1 | |||||
Colour Temperature | 9300K | |||||
Viewing Angle | 160° | |||||
Input Voltage | AC100~240V50/60Hz | |||||
Single-box power | 75W | 75W | 70W | 70W | 56W | 56W |
Maximum power | 1200W | 1200W | 1120W | 1120W | 896W | 896W |
Installation/maintenance | Front and rear installation/front maintenance | |||||
method | ||||||
The surface of the lamp | IP54(Surface clean with water) | |||||
board | ||||||
IP protection level | ||||||
Working temperature | -10℃~+60℃ | |||||
range | ||||||
Working humidity range | 10%RH~90%RH | |||||
Storage temperature range | -20℃~+60℃ | |||||
Storage humidity range | 10%RH~90%RH |
