Product Characteristics

The P3.0 outdoor display screen, with its high resolution and outstanding performance, has become an excellent choice in the outdoor display field. "P3.0" refers to a pixel pitch of 3 millimeters. Compared with displays with a larger pixel pitch, it can present more delicate and clear images, with sharp text edges and rich image details. Even when viewed up close, there will be no pixel graininess, greatly enhancing the visual experience.

From a technical perspective, the P3.0 outdoor display screen adopts advanced LED packaging technology, featuring outstanding stability and durability. The protection level reaches IP65 or above, dust-proof and water-proof, and can withstand severe weather conditions such as heavy rain and sandstorms. It has a wide operating temperature range and can operate stably in an environment from -20℃ to 60℃, adapting to different regional and climatic conditions. Its modular design is convenient for installation and maintenance. If a certain module malfunctions, it can be quickly disassembled and replaced, reducing downtime.

In application scenarios, the P3.0 outdoor display screen is widely used in urban commercial centers, transportation hubs and other places. In the business field, it is used to play high-definition advertisements and brand promotion videos to attract consumers' attention. In the transportation industry, it can be used as an intelligent traffic guidance screen to display road conditions and navigation information in real time. At large-scale event sites, it can present high-definition on-site images and event information, create a lively atmosphere, and effectively meet diverse outdoor display needs.

Product Parameters

Module size :192mm*192mm

Module resolution :64 points *64 points

Maximum power consumption: The maximum power consumption of the unit product is ≤32W per block, or the maximum per square meter

The maximum power consumption is ≤860W/m²

Average power consumption :280W/m

Power consumption in sleep mode: Power consumption when the display screen goes black and does not light up

≤5W per block, black screen ≤120W/m ²

Power supply mode :DC4.2V to DC5V

Electrical protection: Through overcurrent, open circuit, short circuit, overvoltage, undervoltage,

Tests such as over-temperature, over-load and power failure

Maximum brightness :≥3000cd/m ²

Brightness uniformity :IGU≥95%

Chromaticity uniformity: within ±0.002

Deviation of the center distance of the light-emitting point :≤1%

Contrast ratio :≥8000:1

Viewing Angle: Horizontal viewing Angle ≥140°, vertical viewing Angle ≥140°

Brightness adjustment: Supports automatic adjustment of brightness according to changes in ambient illuminance

The function supports 0-100% stepless adjustment through the accompanying software

It supports grayscale adjustment from 0 to 255 levels

Color temperature: White balance 6500K±5%

Color temperature error: When the color temperature is 6500K, it is 100%,75%,50%,25%

The color temperature adjustment error of the four-speed plain white field is ≤200K

Operating ambient temperature :-10℃ to 40℃

Operating environment humidity :10% to 90%RH, no condensation
