The P4.0 outdoor display screen is a commonly used device in the outdoor display field. With its specification characteristics, it plays an important role in multiple scenarios.
Product Characteristics
The P4.0 outdoor display screen is a commonly used device in the outdoor display field. With its specification characteristics, it plays an important role in multiple scenarios.
From the perspective of technical parameters, P4.0 refers to a pixel pitch of 4 millimeters. This pitch enables the display screen to have the advantages of both high-definition display and long-distance viewing. It adopts high-brightness LED beads, with a brightness of over 5500cd/㎡. Even in the daytime when the strong light is directly shining, the picture is still clearly visible. With a refresh rate of 3840Hz, when playing dynamic images such as live sports events and advertising videos, there is no trailing or lag, and the visual experience is smooth. Meanwhile, it has a wide viewing Angle of over 170°, meeting the viewing needs of a large number of people outdoors from different angles.
In terms of protection performance, the P4.0 outdoor display screen has an outstanding protection level, reaching IP65 or above standards. The front panel is dust-proof and water-proof, and can resist the invasion of dust and rain. The box body is treated with a special process, featuring excellent moisture-proof and anti-corrosion capabilities. It can adapt to complex outdoor environments such as high temperature, high humidity, and salt spray areas, thereby extending the service life of the equipment.
In terms of application scenarios, the P4.0 outdoor display screen is often used for commercial advertisements. It is installed on the exterior walls of shopping malls and busy streets, presenting advertising content with clear and vivid images to attract consumers' attention. It is also applicable to traffic guidance. On the traffic guidance screens on expressways and main urban roads, information such as road conditions and vehicle speeds is displayed in real time, providing accurate guidance for travelers. It can also be used at large-scale event sites, such as concerts and sports events, to play live scenes and athlete information in real time, creating a lively atmosphere. With these features, the P4.0 outdoor display becomes a reliable choice for outdoor information display.
Product Parameters
Point spacing(mm) | 4 | 5 | 6.66 | 8 | 10 |
Pixel density | 62500 | 40000 | 22500 | 15625 | 10000 |
Module size(mm) | 320*160 | ||||
Module resolution | 80x40 | 64x32 | 48x24 | 40x20 | 32x16 |
Scanning method | 1/20 | 1/16 | 1/12 | 1/10 | 1/8 |
Surface hardness | 4H | ||||
Surface treatment | Matte black face | ||||
Box size(mm) | 1280x960 | ||||
Box resolution | 320x240 | 256x192 | 192x144 | 160x120 | 128x96 |
Box weight(kg) | 37 | ||||
Box material | Sheet metal iron | ||||
Control system | Nova | ||||
White balance luminance (cd/m) | 4500-5500 | 5000-5500 | 5500-6000 | 5500-6000 | 6000-6500 |
Refresh rate(HZ) | ≥3840 | ||||
Contrast | 80000:1 | ||||
Color temperature | 6500K(adjustable from 1000 to 20000K) | ||||
Viewing Angle(° | 140/140 | ||||
Maximum power(w/m) | 860 | ||||
Average power(w/m) | 270 | ||||
Installation/maintenance method | Pre-maintenance | ||||
Working temperature range | -10℃~+60℃ | ||||
Working humidity range | 10%RH~90%RH | ||||
Storage temperature range | -20℃~+60℃ | ||||
Storage humidity range | 10%RH~90%RH |
